Pro Spot VAC-U-PULL Dent Pulling Tower (Product Family: VAC-U-PULL-L, VAC-U-PULL-XL, VAC-U-PULL-XL-LB)

Pro Spot

VAC-U-PULL Dent Pulling Tower (Product Family: VAC-U-PULL-L, VAC-U-PULL-XL, VAC-U-PULL-XL-LB)

Dent Pulling Systems & Towers

VAC-U-PULL is a mobile dent pulling tower with a vacuum system that seals to the floor, so the tower is secured without hooks, straps or anchors. It comes in VAC-U-PULL-L, VAC-U-PULL-XL and VAC-U-PULL-XL-LB configurations, with an optional Lever Bar Kit and anchor plate for the XL and an extension kit for the L. This listing covers the family rather than one model.

Model

Choose a model to add this product to your project.

Pulling force
500 lb (220 kg)
Air pressure
60 PSI
Operating height
3.5-54 in
Weight
56 lb (25.4 kg)

Key specifications

VAC-U-PULL-XL weight
61 lb (27.7 kg)
VAC-U-PULL-L weight
56 lb (25.4 kg)
VAC-U-PULL-XL dimensions
73 H x 19 W x 32 D in (185.4 x 48.2 x 81.2 cm)
VAC-U-PULL-L dimensions
56.5 H x 16 W x 28 D in (143.5 x 40.6 x 71 cm)
VAC-U-PULL-XL maximum pulling force
550 lb (249 kg)
VAC-U-PULL-XL air pressure
75 PSI
Specifications
Quantity
1
Request a Quote

Nothing is purchased online. TAG confirms configuration with you.

Choose a model above before adding this product to your project.

Not in your project yet

Configure This ModelChoose AccessoriesRequest Consultation

Fit & requirements

Review the space and utility needs for this model with TAG before ordering.

VAC-U-PULL-XL air pressure
75 PSI
VAC-U-PULL-XL dimensions
73 H x 19 W x 32 D in (185.4 x 48.2 x 81.2 cm)
VAC-U-PULL-XL weight
61 lb (27.7 kg)
VAC-U-PULL-L air pressure
60 PSI
VAC-U-PULL-L dimensions
56.5 H x 16 W x 28 D in (143.5 x 40.6 x 71 cm)
VAC-U-PULL-L weight
56 lb (25.4 kg)

What TAG confirms with you

  • Bay dimensions, ceiling height and working clearances
  • Floor slab thickness, condition and anchoring
  • Electrical service, air supply and any drainage needed
  • Vehicle mix, throughput and how the bay is used day to day
  • Delivery access, rigging and installation scope

Two pulling forces

VAC-U-PULL-L is rated at 500 lb (220 kg); VAC-U-PULL-XL is rated at 550 lb (249 kg).

Shop air powered

air pressure is 60 PSI on the L and 75 PSI on the XL.

Operating height

3.5-54 in on the L and 3.5-65 in on the XL.

System Specifications

VAC-U-PULL-L: 500 lb (220 kg) maximum pulling force; 60 PSI air pressure; 3.5-54 in (8.9-137 cm) operating height; 56.5 H x 16 W x 28 D in; 56 lb (25.4 kg).

ConfigurationPulling forceAir pressureOperating heightWeight
VAC-U-PULL-L500 lb (220 kg)60 PSI3.5-54 in56 lb (25.4 kg)
VAC-U-PULL-XL550 lb (249 kg)75 PSI3.5-65 in61 lb (27.7 kg)
VAC-U-PULL-XL maximum pulling force
550 lb (249 kg)
VAC-U-PULL-XL air pressure
75 PSI
VAC-U-PULL-XL operating height
3.5-65 in (89 mm-165 cm)
VAC-U-PULL-XL dimensions
73 H x 19 W x 32 D in (185.4 x 48.2 x 81.2 cm)
VAC-U-PULL-XL weight
61 lb (27.7 kg)
VAC-U-PULL-L maximum pulling force
500 lb (220 kg)
VAC-U-PULL-L air pressure
60 PSI
VAC-U-PULL-L operating height
3.5-54 in (8.9-137 cm)
VAC-U-PULL-L dimensions
56.5 H x 16 W x 28 D in (143.5 x 40.6 x 71 cm)
VAC-U-PULL-L weight
56 lb (25.4 kg)

What ships with it

The XL and XL-LB ship with different parts, so each list is kept separate. VAC-U-PULL-L is not listed here.

VAC-U-PULL-XL

Supplied components
16
Listed as optional
1
Included components (16 items)
  • TowerPart no. 90-2523
  • Fitting, BulkheadPart no. F-51
  • Vacuum Ejector Venturi MufflerPart no. SA-0148
  • MufflerPart no. 51-0183
  • Cotter Pin, zinc-plated spring steel for 3/8"-1/2" pin dia., 1/16" wire dia.Part no. 51-0167
  • 6 Hook (Claw) Assy with Eye BoltPart no. SA-0812
  • Gasket SetPart no. 90-25262 ea
  • Knob, Four-Arm, with M10x35" threaded studPart no. 51-0151
  • Guide Bushing, SliderPart no. 90-2532
  • End Cap, 2" x 4"Part no. P10-35
  • Air Supply, Regulator AssyPart no. SA-0813
  • Adjustable Clevis PinPart no. 51-0168
  • Hand Winch with Belt, black 19mm hookPart no. 82-0300
  • Ball ValvePart no. F-1085
  • Slider Assy, WinchPart no. SA-0820
  • Wheel Center, polypropylene 125mm x 32mmPart no. 51-0164

View full component sheet

Listed as optional

The manufacturer prints these as optional — they are not included with the machine. TAG confirms exactly what is on your project before quoting.

  • Lever Bar Retrofit KitPart no. VAC-LB-RK

Shipping data

Crate figures for transport planning. These are not operating specifications.

Shipping dimensions
40" x 32" x 72" (1m x 0.8m x 1.83m)
Shipping weight
65 lbs (29.5 kg)

Source: Pro Spot Component List CL-VAC-U-PULL-XL Rev 1.1.

VAC-U-PULL-XL-LB

Supplied components
19
Listed as optional
1
Included components (19 items)
  • TowerPart no. 90-2523
  • Fitting, BulkheadPart no. F-51
  • Vacuum Ejector Venturi MufflerPart no. SA-0148
  • MufflerPart no. 51-0183
  • Cotter Pin, zinc-plated spring steel for 3/8"-1/2" pin dia., 1/16" wire dia.Part no. 51-0167
  • 6 Hook (Claw) with Eye BoltPart no. SA-0812
  • Gasket SetPart no. 90-25262 ea
  • 6FT ChainPart no. 90-3005
  • Lever BarPart no. SA-0912
  • Knob, Four-Arm, with M10x35" threaded studPart no. 51-0151
  • Guide Bushing, SliderPart no. 90-2532
  • End Cap, 2" x 4"Part no. P10-35
  • Air Supply, Regulator AssyPart no. SA-0813
  • Adjustable Clevis PinPart no. 51-0168
  • Hand Winch with Belt, black 9mm hookPart no. 82-0300
  • Ball ValvePart no. F-1085
  • Slider Assy, WinchPart no. SA-0820
  • Wheel Center, polypropylene 125mm x 32mmPart no. 51-0164
  • CarabinersPart no. 51-0219

View full component sheet

Listed as optional

The manufacturer prints these as optional — they are not included with the machine. TAG confirms exactly what is on your project before quoting.

  • Slide Tube with Claw Hook for Lever BarPart no. SA-0915

Shipping data

Crate figures for transport planning. These are not operating specifications.

Shipping dimensions
40" x 32" x 72" (1m x 0.8m x 1.83m)
Shipping weight
85 lbs (38.5 kg)

Source: Pro Spot Component List CL-VAC-U-PULL-XL-LB Rev 1.0.

Configure this VAC-U-PULL Dent Pulling Tower (Product Family: VAC-U-PULL-L, VAC-U-PULL-XL, VAC-U-PULL-XL-LB)

Add the machine to your TAG Project and the configuration steps — quantity, installation, training and site readiness — open right here. Nothing is priced or ordered online.

Accessories for VAC-U-PULL Dent Pulling Tower (Product Family: VAC-U-PULL-L, VAC-U-PULL-XL, VAC-U-PULL-XL-LB)

TAG confirms final fit and configuration before purchase.

9 of 9 shown

Optional accessory · 9

  • Optional accessory

    Pro Spot VAC-LB-RK Lever Bar Kit

    Part no. VAC-LB-RK

    Lever bar kit for the VAC-U-PULL-XL dent pulling tower. It is available as a retrofit kit or can be purchased together with the tower as VAC-U-PULL-XL-LB.

    Fits this model.

    Full Details

  • Optional accessory

    Pro Spot VAC-EXT Vac-U-Pull Extension Kit

    Part no. VAC-EXT

    Optional add on extension kit for the VAC-U-PULL-L dent pulling tower. It is an enhancement for dent repairs on high profile vehicles such as trucks and delivery vans.

    Fits this model.

    Full Details

  • Optional accessory

    Pro Spot Floor gasket seal for VAC-U-PULL (56" tall)

    Part no. 84-0501

    Pro Spot 84-0501 — Floor gasket seal for VAC-U-PULL (56" tall). Stocked and supplied by TAG Auto Equipment.

    Fits this model.

    Full Details

  • Optional accessory

    Pro Spot Muffler for SA-0148: Vacuum Ejector Venturi

    Part no. 51-0183

    Pro Spot 51-0183 — 51-0183 - Muffler for SA-0148: Vacuum Ejector Venturi. Stocked and supplied by TAG Auto Equipment.

    Fits this model.

    Full Details

  • Optional accessory

    Pro Spot Air Regulator for VAC-U-PULL-XL

    Part no. SA-0813

    Pro Spot SA-0813 — SA-0813 - Air Regulator for VAC. Stocked and supplied by TAG Auto Equipment.

    Fits this model.

    Full Details

  • Optional accessory

    Pro Spot 6 Hook Claw

    Part no. SA-0812

    Pro Spot SA-0812 — SA-0812 - 6 Hook Claw. Stocked and supplied by TAG Auto Equipment.

    Fits this model.

    Full Details
